SimonsVoss WaveNet - Page 206

WNM.RN.R.IO
transfer media Interfaces Power supply Dimensions
 868MHz
 connecting terminals for
an external plug-in
power supply
 FME bushing (antenna)
 Molex PicoBlade 10-pin
(IO connector)
9V
DC
bis 12V
DC
, min. 3VA
98×64×40mm
or
98×64×130mm
with antenna
WNM.RN.CC.IO
transfer media Interfaces Power supply Dimensions
 RS-485
 connecting terminals for
an external plug-in
power supply
 Connection terminals for
RS-485
 Molex PicoBlade 10-pin
(IO connector)
9V
DC
bis 12V
DC
, min. 3VA 98×64×40mm
WNM.RN.CR.IO
transfer media Interfaces Power supply Dimensions
 868MHz
 RS-485
 connecting terminals for
an external plug-in
power supply
 Connection terminals for
RS-485
 FME bushing (antenna)
 Molex PicoBlade 10-pol
(IO connector)
9V
DC
bis 12V
DC
, min. 3VA
98×64×40mm
or
98×64×130mm
(with antenna
WaveNet (Manual)
8. Technical specifications
206 / 210
