SimonsVoss WaveNet - RouterNode Specifications

 Remote opening
 Activation
Adjustable delay between event and reaction (RouterNode 2)
 0s
 8s
 16s
 24s
 32s
 RingCast (see RingCast [}93] )
8.2 RouterNodes
WNM.RN2.ER.IO
transfer media Interfaces Power supply Dimensions
 868MHz
 Ethernet
 RJ45 (Network/PoE)
 Round plug Ø 5.5 mm, Ø
pin 2.0 mm (power
supply)
 Screw terminal block 2-
pole, wire diameter 0.14
mm
2
to 1.5 mm
2
(IO-V
out
for external
applications)
 FME socket (optional
external antenna)
 Spring terminal block 10-
pin, wire diameter 0.14
(rigid) or 0.2 (flexible)
mm
2
to 0.5 mm
2
(IO
connector)
9 V
DC
to 32 V
DC
or PoE ac-
cording to IEEE 802.3af, 3 W
Power supply via PoE and
round plug simultaneously
possible: Round plug > 12
VDC →
Round plug used,
round plug < 12 VDC → PoE
used
172.1×85.9×32.8
mm
WaveNet (Manual)
8. Technical specifications
205 / 210
