5.4.5 RingCast
RN2
1
RN2
2
RN2
3
RN2
4
RN2
5
RN2
"Initiator"
RN2
4a
RN2
4b
RN2
4c
1. Ethernet
2. 868 MHz
1. Ethernet
2. 868 MHz
1. Ethernet
2. 868 MHz
1. Ethernet
2. 868 MHz
1. Ethernet
2. 868 MHz
1. Ethernet
2. 868 MHz
1. Ethernet
2. 868 MHz
1. Ethernet
2. 868 MHz
Only
Ethernet
Only
Ethernet
Depending on the firmware version of the router and LockNodes, some
individual functions are not available (see
Firmware information [}39] ).
NOTE
Version-dependent availability of RingCast in WaveNet Manager
From version 2.6.7, the WaveNet Manager supports all RingCast functions
described above.
With RingCast, an input signal from a specific RouterNode ("Initiator") can
be passed on to all networked RouterNodes without having to wire all
inputs of the RouterNodes. If a signal arrives at the initiator at an input with
a RingCast, the signal is forwarded to all RouterNodes connected to the
RingCast and the RouterNodes react as if a signal were actually present at
their input.
