SimonsVoss WaveNet - In LSM

Device Signalling Meaning reaction
WN.RP.CC
Permanent lights (yel-
low LED)
Power supply avail-
able.
Light (green LED)
Upstream_Data trans-
mission.
Lights (dark green
LED)
Downstream data
transmission.
Permanent light (red
LED)
Software or hardware
defect.
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Replace the device
(see
Reprogram or
replace the device
[}154] ).
WN.RN2
Flashing (alternating
red and green)
Reset is performed
(firmware dependent).
Flashing, 1.5 (green)
no WaveNet configur-
ation present.
1. Add the
RouterNode to your
WaveNet (see
Add
RouterNode to
WaveNet [}53] ).
Flashing, 1 s
WaveNet configura-
tion available, Router-
Node is ready for oper-
ation.
Flashing, 0.5 s Data transfer.
Permanent light (red
LED)
Software or hardware
defect.
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Replace the device
(see
Reprogram or
replace the device
[}154] ).
7.1 In LSM
You can view some information about the operating status directly from
LSM. This includes:
 Battery status (read lock)
WaveNet (Manual)
7. Signalling the operating status
200 / 210
