Device Signalling Meaning reaction
WN.RN.CC
1x long (yellow LED) Power-on reset.
Light (green LED)
Upstream data trans-
mission (slave sends
to master).
Lights (dark green
LED)
Downstream data
transmission (master
sends to slave).
Permanent light (red
LED)
Software or hardware
defect.
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Replace the device
(see
Reprogram or
replace the device
[}154] ).
WN.CN.UX
1x long (yellow LED)
USB correctly detec-
ted and power-on re-
set.
Flashing, slow (green
LED)
Ready to receive
Flashing, fast (green
LED)
Data transfer from/to
LockNode.
Permanent light (red
LED)
Software or hardware
defect.
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Replace the device
(see
Reprogram or
replace the device
[}154] ).
