7 Signalling the operating status
RouterNodes
Device Signalling Meaning reaction
WNM.RN2.ER.IO
Flashing, ~1.5 Hz
(green LED on cover)
WaveNet configura-
tion available, Router-
Node is ready for oper-
ation.
Flashing, ~0.3 Hz
(green LED on cover)
no WaveNet configur-
ation present.
1. Add the
RouterNode to your
WaveNet (see
Add
RouterNode to
WaveNet [}53] ).
Flashing, briefly (red
LED on cover)
Power-on reset.
Flickering (green LED
on cover)
Data transfer.
Continuous lights (red
LED on cover)
Software or hardware
defect.
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Replace the device
(see
Reprogram or
replace the device
[}154] ).
WNM.RN.R.IO
WNM.RN.CC.IO
WNM.RN.CR.IO
WNM.RN.EC.IO
Flashing, ~1.5 Hz
(green LED)
Ready to receive.
Flashing (green LED) Data transfer.
Permanent light (red
LED)
 Software problem
 Problem with the
power supply
 Hardware problem
1. Perform a power-
on reset (see
RouterNodes
[}150] ).
2. Check the power
supply.
3. Replace the device
(see
Reprogram or
replace the device
[}154] ).
