5.6.1 Overview
You can see the topology of your WaveNet in the WaveNet Manager on the
start page.
The overview provides the following information:
Router node
RouterNode type (e.g. RN_ER_IO)
Input address (for example 0x0006)
Chip ID (e.g. 89003644)
Host name (If you do not use host names, the IP address is displayed
instead of the host name).
RSSI value (if radio interface only. Not used in the example)
LockNode
LockNode type (e.g. LN_I)
Address (e.g. 0x0027)
Chip ID (e.g. 00017023)
Name of the linked locking device
RSSI value (e.g. -33dBm)
You can determine the segments with the displayed address (see
Addressing [}42]
).
Number of device types
The WaveNet Manager provides you with a way to display the number of
different device types.
ü WaveNet Manager opened via LSM (see
Best Practice: From the LSM
software [}37]
)
1. Right click the entry WaveNet_XX_X.
9 The window "Administration" opens.
