WNM.LN.R
transfer media Interfaces Power supply Dimensions
 868MHz
 25kHz
 3 inputs (potential-free,
pulses in 2 Hz cycle :
1ms, 35µA)
 Output (open drain, max.
25 V
DC
, max. 650 mA
continuous current (2 A
inrush current - contact
resistance 0.5 Ω
)
IO cable with 6-pin
Molex connector
required
(WN.LN.SENSOR.CABLE
)
2x CR
2
/
3
AA (lithium 3,6V -
tadiran SL-761)
Service life approx. 6 years
37×Ø53mm
WNM.LN.C
transfer media Interfaces Power supply Dimensions
 25kHz
 Connection terminals for
RS-485
 Connection terminals for
external power supply
 Output (open drain, max.
25 V
DC
, max. 650 mA
continuous current (2 A
inrush current - contact
resistance 0.5 Ω
)
IO cable with 6-pin
Molex connector
required
(WN.LN.SENSOR.CABLE
)
9V
DC
bis 24V
DC
, ~15mA 37×Ø53mm
