The second four switches (5 - 8) of DIP switch SW2 (shown in Figure 4) are
used to program the "Alarm/Manual EVAC" Message. The first four switches (1
- 4) perform the same function for the second message ("All Clear"). As shown
in Figure 4, switches SW2-2 through SW2-4 select the Tone; switch SW2-1
selects the Voice/No Voice Message for MSG2. For the “
Note: Using three switches for tone selection allows seven different tones.
Standard tone options available with the VCP are shown in Table 1.
Table 1. Standard Tone Options Available with the VCP
Tone Option
SW2 EVAC
DIP Switch
Settings
SW2 MSG 2
DIP Switch
Settings
5 6 7 8 1 2 3 4
No Tone V* 0 0 0 V* 0 0 0
Slow Whoop V* 0 0 1 V* 0 0 1
Chime V* 0 1 0 V* 0 1 0
Hi/Lo V* 0 1 1 V* 0 1 1
Horn - 120 Beats per Minute V* 1 0 0 V* 1 0 0
Horn - 20 Beats per Minute V* 1 0 1 V* 1 0 1
Bell - 60 Beats per Minute V* 1 1 0 V* 1 1 0
Bell - (Continuous) V* 1 1 1 V* 1 1 1
V = Set to 0 for TONE ONLY; set to 1 for SPOKEN MESSAGE WITH PRE-TONE.
Continued on next page
Message and Tone Initiation, Continued
Adjunct Configuration
(continued)
Standard Tone Options
To Next Page
