27
The 4003 has the following system wiring configurations:
• Adjunct to the 4001 System
• Adjunct to the 4002 System
• Slave to the 4020 System
• Stand-Alone System
• Remote Microphone.
The 4003 terminal blocks are labeled with a "TB number", and each terminal on
the terminal block has a number. (For example, Terminal No.1 on Terminal
Block No. 1 is labeled TB1-1.)
Each terminal on the terminal block is also identified with an abbreviation of the
circuit wire that is connected to it. (For example, TB1-1 on the 565-358 Voice
Controller Assembly is labeled "RUI -".)
Continued on next page
System Wiring Configurations
Configurations
Important Notes:
To Next Page
