9
Selection of temporal code for Horn, Bell, Whoop, or Chime tones is available
by selecting the desired tone with the DIP switch, and by installing jumper P3 to
position 2-3 on the voice controller assembly (565-358). Temporal coded horn
is selected by picking any horn tone. The other tones require the continuous
setting.
Voice message selection is accomplished by specifying the location in message
memory for the Evacuation and Second messages when the message chip is
being built. The Evacuation Message is located at phrase location 89. The
Second Message is located at phrase location 90. Custom message chips have
alternate messages at these locations, and are limited to complete spoken
messages. No message splicing is available.
The microphone pre-tone is the Chime Tone, played three times.
In the Slave configuration, Walk Test phrases are generated by the 4020 Master
Controller, exactly like the 4100 audio system. Spoken Walk Test is not
available in the Adjunct configuration.
Message and Tone Initiation, Continued
Temporal Code Selection
Voice Message Selection
Microphone Pre-tone
Walk Test Phrases
