Simplex 4008-9101 - Diagnostics

Chapter 8. Operating
8-5
Setting the Time and Date
Selecting the "Set Time/Date" option from the main menu
allows you to change the system time and date. This opera-
tion is protected at Access Level 2.
<ENTER>=Accept
[11]:23 pm 11/12/03
The Right/Left arrow keys allow you to move the focus from
field-to-field for editing. The <NEXT/PREV> keys allow
you to change the currently selected fields. The am/pm field
and the day-of-week field are not editable.
Reports
Reports, which are either text-based archives of system
activity or a text-based description of the panel configura-
tion, can be archived and printed in the following manner.
• The panel supports an unsupervised, 80-column serial
printer that can be used to record events, or to print his-
tory log reports.
• Use Windows Hyperterminal (or similar application), as
follows:
a. Connect a 733-794 download cable between the
Service Port on the panel and a serial communica-
tion port on the PC.
a. Create a connection profile for the serial port. Set
the serial communication parameters to 9600 baud,
8 bits, no parity, 1 stop bit, and no flow control.
a. Configure the application to capture the informa-
tion coming in on the serial port. (Choose Capture
Text in the Hyperterminal Transfer menu.)
To generate a report, do the following.
1. Press <MENU>.
2. Press <NEXT> and <PREV> until the following
prompt appears.
<ENTER>=Accept
Menu: [Reports]
3. Press <ENTER>. A prompt similar to the following
appears.
<ENTER>=Accept
Rep: [ALOG]
4. Use the <NEXT> or <PREV> key to select one of the
options described in Table 8-4.
5. Press <ENTER>. The panel displays a message noting
that the report has been sent to the printer.
Diagnostics
Use the following procedure to run the panel’s diagnostic
options.
1. Press <MENU>.
2. Press <NEXT> and <PREV> until the following
prompt appears.
Control Point
Bypass
Bypasses the following control points
(causes a trouble):
• On-til-Silence NACs
• On-til-Reset NACs/relays
Elevator
Bypass
Bypasses Elevator Recall operation
(causes a trouble)
Doorholder
Bypass
Bypasses the door holder operation
(causes a trouble)
Lamp Test Illuminates all LEDs and LCD segments
on the operator interface.
Earth Fault
Latch
Latches intermittent Earth troubles in the
panel, preventing them from automati-
cally clearing.
Display Time Shows the current time and date.
Send DACT
Test
Sends the DACT test event to the sta-
tionary station.
Table 8-3 Control Functions (Continued)
Function Description
Table 8-4 Reports
Report Description
ALOG Displays contents of alarm log.
SLOG Displays contents of supervisory log.
TLOG Displays contents of trouble log.
CLOG Combined alarm, supervisory, and trou-
ble logs.
CONFIG Text description - including custom label,
function type
