Simplex Contact Closure DACT User Manual

vii
Figure 1-1. Telephone System Connection (Each Line) ................................ 1-3
Figure 2-1. Installing a 4004-9810 CCDACT Kit.......................................... 2-4
Figure 2-2. Wiring the 4004-9810 CCDACT into the System....................... 2-5
Figure 2-3. Installing a 4005-9810 CCDACT Kit.......................................... 2-6
Figure 2-4. Wiring the 4005-9810 CCDACT into the System....................... 2-7
Figure 2-5. Installing a 4020-0153 CCDACT Kit.......................................... 2-8
Figure 2-6. Wiring the 4020-0153 CCDACT into the System..................... 2-10
Figure 2-7. Installing a 4100/4120-0153 CCDACT Kit............................... 2-12
Figure 2-8. Wiring the 4100/4120-0153 CCDACT into the System............ 2-13
Figure 3-1. Show Command Screen............................................................. 3-17
Figure 3-2. Report Code Command Screen ................................................. 3-18
Figure 3-3. Help Command Screen.............................................................. 3-18
List of Figures
