Simplicity LTH Series Service Manual

1 General Information
Specifications
1 - 12
Motor Fixed Displacement Piston
Hydraulic Fluid 3.5 Quarts (3.3 L) SAE 20W-50 Premium
Control Single Lever Release
Lever for Manual Tractor Movement,
Continuously Variable, Forward &
Reverse, without Braking
Speeds Forward: 0-5.5 MPH (0-8 km/h)
@ 3400 RPM Reverse: 0-1.7 MPH (0-2.7 km/h)
Differential Automotive Type
CONTROLS
Steering Full Circle Steering Wheel System Gear
and Sector
Clutch/Brake Location Right Front
Pedal Combination Clutch/Brake/Parking Brake
Pedal Standard Equipment
Location -Mower Lift Lever Right Side, Lower Dash
Tower
-PTO Clutch Electric, Dash Mounted
-Ground Speed Lever Dash Mounted
-Ignition Key Switch on dash panel
-Throttle Lever and Choke Lever on dash
panel
-Light Switch on dash panel
-Separate Indicator Lights for Safety
-Interlock Switch Operator Present
-Transmission Neutral, PTO Disengaged
-Clutch/Brake Pedal Depressed
-Low Oil Pressure Warning Light
CHASSIS
Frame Heavy Gauge Steel Channel
Power Take-Off Point Front
Engine Mounting Above Front Axle
Pivot Point Location Front Axle
Rear Wheels Tire Size 20 x 8.00-10 Turf Type
Pneumatic Inflation Pressure 6-8 psi
(41-55 kPa)
Front Wheels Tire Size 15 x 6.00-6
Pneumatic Inflation Pressure 12-15 psi
(82-103 kPa)
Front Axle 1-3/4” x 3” 12 Ga. Fabricated Rectangular
Tube
Accessibility Hood Tips Forward
Seat Type Bucket, High Back, Adjustable w/
Spring Suspension; Adjustable to Suit
Different Size Operators
Turning Radius Inside Rear Tire 16 In. (40.6 cm)
DIMENSIONS
Tractor
Overall Length 67 In. (170.2 cm)
Overall Width 35 In. (88.9 cm)
Height To Top of Steering Wheel 40 In. (101.6 cm)
To Top of Engine Cover 34 In. (86.7 cm)
Wheel Base 48 In. (121.9 cm)
Weight Net: 455 lbs. (206 kg)
(approx.) w/o Shipping: 575 lbs. (261 kg)
mower
Mower - 38"
Effective
Cutting Width 38 In. (96.5 cm)
Overall Width
with Deflector 49.5 In. (125.7 cm)
Weight 100 lbs. (45 kg)
Variable
Cutting Ht. 1-3.6 in. (2.5 to 91 cm)
Blade
Arrangement Two Blades
Mower Drive V-Belt From Tractor PTO Pulley
Spindle
Bearings Lubricated and Sealed Ball Bearings
Mower - 44"
Effective
Cutting Width 44 In. (111.8 cm)
Overall Width
with Deflector 56 In. (142.2 cm)
Weight 115 lbs. (52 kg)
Variable
Cutting Ht. 1-3.6 In. (2.5 to 91 cm)
Blade
Arrangement Three Staggered Blades
Mower Drive V-Belt From Tractor PTO Pulley
Spindle
Bearings Lubricated and Sealed Ball Bearings
