Simplicity LTH Series Service Manual

1 - 11
1 General Information
Specifications
Capacity: 4 Gallons (15.1 L)
Muffler Quiet Compact, Low Back Pressure
15 HP Briggs & Stratton
Make Briggs & Stratton
Model Vanguard
Horsepower 15 HP @ 3600 rpm
Cylinders 1
Bore 3.44 In. (87.3 mm)
Stroke 3.06 In. (77.7 mm)
Displacement 29.3 Cu. In. (480 cc)
Construction Overhead Valve, Cast Iron Sleeves,
Aluminum Crankcase
Electrical 12 Volt, 9 Amp Alternator Regulated
System Battery: 340 Cold Cranking Amps, 41 min.
Reserve Capacity, Industrial Rated
Starter Motor
Ignition Magnetron Electronic Ignition
Air Cleaner Ducted Paper Cartridge and Foam
Precleaner large 325 sq. in. Air Filtering
System
Lubrication Splash Lube with Circulating Pump & Filter
Oil Capacity 3.5 Pints w/Filter (1.6 L)
Fuel Tank Material: Non-Corrosive Polyethylene
Fuel Tank Gauge Built Into Filler Cap
Capacity: 4 Gallons (15.1 L)
Muffler Quiet Compact, Low Back Pressure
TRANSMISSION
Gear Models
Type Spur Gear
Material Gear: Heat Treated
Shaft: Hardened and Ground
Bearings: Needle Roller, Sealed Ball
and Bushings
Lubrication Bentonite Grease
Speeds Five Forward, One Reverse
@ 3400 rpm 1st: 1.1 MPH (1.8 km/h)
2nd: 2.2 MPH (3.5 km/h)
3rd: 3.4 MPH (5.5 km/h)
4th: 4.2 MPH (6.8 km/h)
5th: 5.1 MPH (8.2 km/h)
Reverse: 2.4 MPH (3.9 km/h)
Differential Spur Gear Type
Hydro Models
Type Hydrostatic
Pump Variable Displacement Piston
Specifications
ENGINE
14 & 16 HP Briggs & Stratton
Make Briggs & Stratton
Model Vanguard V-Twin
Horsepower 14 & 16 HP @ 3600 rpm
Cylinders 2
Bore 2.68 In. (68 mm)
Stroke 2.60 In. (66 mm)
Displacement 29.3 Cu. In. (480 cc)
Construction Overhead Valve, Cast Iron Sleeves,
Aluminum Crankcase
Electrical 12 Volt, 16 Amp Alternator Regulated
System Battery: 340 Cold Cranking Amps, 41 min.
Reserve Capacity, Industrial Rated
Starter Motor
Ignition Magnetron Electronic Ignition
Air Cleaner Ducted Paper Cartridge and Foam
Precleaner large 325 sq. in. Air Filtering
System
Lubrication Full Pressure Lube w/Oil Filter
Oil Capacity 3.5 Pints w/Filter (1.6 L)
Fuel Tank Material: Non-Corrosive Polyethylene
Fuel Tank Gauge Built Into Filler Cap
Capacity: 4 Gallons (15.1 L)
Muffler Quiet Compact, Low Back Pressure
14 HP Kohler
Make Kohler
Model Command™
Horsepower 14 HP @ 3600 rpm
Cylinders 1
Bore 3.43 In. (87 mm)
Stroke 2.64 In. (67 mm)
Displacement 24.3 Cu. In. (398 cc)
Construction Overhead Valve, Cast Iron Sleeves,
Aluminum Crankcase
Electrical 12 Volt, 15 Amp Alternator Regulated
System Battery: 340 Cold Cranking Amps, 41 min.
Reserve Capacity
Ignition High Energy Electronic Ignition
Air Cleaner Ducted Paper Cartridge and Foam
Precleaner
Lubrication Full Pressure Lube w/Oil Filter
Oil Capacity 4.0 Pints w/Filter (1.9 L)
Fuel Tank Material: Non-Corrosive Polyethylene
Fuel Tank Gauge Built Into Filler Cap
