Simplicity LTH Series Service Manual

7 - 81
7 Transmission Repair
7D Hydro-Gear 0750 / 0800
1 2 WASHER, 7/16 x 1 x 1/2
2 2 BALL BEARING (Model 311-0800)
3 1 SEAL, Lip
4 1 RETAINING RING
5 1 ARM, Bypass
6 1 SEAL, Lip
7 1 SETSCREW
8 1 ARM, Control
9 2 PIN, Actuating
10 1 NUT, Hex, Lock, 5/16-24
11 1 SEAL, Lip
12 1 RETAINING RING
13 1 ARM, Actuating
14 1 CASTLE NUT, 5/16-24
15 1 PUCK, Dampener
16 1 DRIVE PIN
17 1 SPRING, Extension
18 1 STUD, 5/16-24
19 1 SPRING, Compression
20 1 HOUSING, Lower
21 1 HOUSING, Upper
22 1 RING, Wire
23 1 BALL BEARING, Shaft
24 2 BEARING, Cradle
25 1 BEARING, Thrust
26 1 SWASHPLATE
27 1 BLOCK, Cylinder
28 1 ARM, Trunnion
29 1 GUIDE, Slot
30 1 SHAFT, Motor (Model 311-0800)
31 1 BEARING, Thrust
32 1 BLOCK, Cylinder
33 1 ACTUATOR, Bypass
34 1 CENTER SECTION ASSY. (Model 311-0800)
35 1 SEAL, Lip
36 1 RETAINING RING
37 2 WASHER, 17/64 x 23/64 x 1
38 1 ELEMENT, Oil Filter
39 1 BOLT, 5/16-18 x 1-3/4
40 4 BRAKE ROTOR/STATOR KIT
41 1 DIFFERENTIAL ASSY.
42 2 WASHER, 3/4 X 1-1/2 X 1/32
43 2 SEAL, 3/4 X 1-1/4 X 1/4
44 1 SHAFT, Input
45 21 BOLT, 1/4-20 x 1-3/8
46 2 PIN, 1/2 O.D. x 7/16 I.D. x 3/4
47 1 JACK SHAFT/PINION GEAR ASSY. (Incl. Ref.
Nos. 1, 48, 49 & 60)
48 1 JACK SHAFT
49 2 CAPSCREW, 6 mm x 13/64
50 6 SEAL, Wiper
51 1 SPRING, Block
52 1 WASHER, Block Thrust
53 1 VENT CAP ASSY.
54 1 FITTING & O-RING ASSY.
55 1 SHAFT, Motor (Model 311-0750)
56 2 SLEEVE BEARING (Model 311-0750)
57 1 CENTER SECTION ASSY. (Model 311-0750)
58 1 COTTER PIN
59 1 WASHER, 7/16 x 7/8 x 51/64
60 1 PINION GEAR (See Ref. No. 47)
Ref. Qt. Description Ref. Qt. Description
