8 Mower Deck Repair
Height Adjustment & Rollers
Ref. Qt. Description Ref. Qt. Description
1 1 PIN, Clevis
2 1 RING, Retaining
3 1 BOLT, Shoulder, 3/8-16
4 1 CLIP, Pin, Safety
5 1 PIN, Roll, 1"
6 2 NUT, Hex Hd., 3/8-16
7 2 LOCKWASHER, 3/8
8 2 SPACER
9 6 SCREW, Hex, Taptite, 5/16 x 3/4
10 2 STRAP, Mower Arm Assy.
11 8 ROLLER
12 1 SLIDE
13 1 BAR, Roller
14 1 STRAP, Trunnion Retainer
15 1 TRUNNION
16 1 NUT, Adjustor
17 1 ARM, Rear, Mower, RH
18 1 TRUNNION
19 1 TRUNNION, Threaded
20 1 ROD, Adjustment
21 1 CRANK, Cutting Height
22 1 WASHER, Detent
23 1 ARM ASSY., Mower
24 1 INDICATOR, Cutting Height
25 1 PLATE, Support
26 1 BRACKET, Cutting Height
27 1 LINK ASSY., Lift
28 1 SHAFT ASSY., Roller
29 1 SPACER
30 1 KNOB
31 2 NUT, Hex, Jam, 1/2-13
32 4 LOCKWASHER, 5/16
33 4 NUT, Hex, 5/16-18
34 1 COTTER PIN
35 1 COTTER PIN
36 1 WASHER, Flat, 5/16
37 4 CAPSCREW, Hex Hd., 5/16-18 x 1-1/4
38 1 CAPSCREW, Hex Hd., 3/8-16 x 1-3/4
39 1 WASHER, Plain, 1/2
40 8 WASHER, Plain, 41/64 x 1-1/4
41 3 WASHER, Plain, 13/32
42 1 NUT, Hex, Whizlock, 3/8-16
43 2 NUT, Hex, Flange, Lock, 1/2-13
44 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
45 1 PAL NUT
46 3 WASHER, 33/64
38" Mower Deck - Height Adjustment & Rollers
