8 - 9
8 Mower Deck Repair
44” Deck & Arbors
1 6 BEARING
2 3 HOUSING, Arbor, Top
3 3 ADAPTER, Blade
4 3 WASHER, Spring
5 3 WASHER, Spline
6 3 SHIELD, Grass, Upper
7 25 SCREW, Hex, Taptite, 5/16-18 x 3/4
8 3 COLLAR, Mower Arbor
9 3 ARBOR SHAFT KIT (Includes Ref. No. 8)
10 3 ARBOR SHAFT ASSY.
(Incl. Ref. Nos. 1, 8 & 9)
11 1 MOWER HOUSING ASSY.
12 3 SHIELD, Grass, Bottom
13 3 WASHER, Shim
14 3 HOUSING ASSY., Arbor, Bottom
(Incl. Ref. Nos. 19 & 26)
15 1 COVER, Arbor
16 3 BLADE, Mower
17 1 PULLEY ASSY.
18 2 PULLEY ASSY., Deck Drive
19 3 GREASE FITTING
20 1 COVER, Arbor
21 1 CLAMP
22 1 SPRING
23 1 PLUG, Hole
24 1 DEFLECTOR, Plastic
25 1 ROD, Deflector, Front
26 3 GASKET, Foam
27 2 NUT, Hex, 1/4-20
28 2 LOCKWASHER, 1/4
29 3 LOCKWASHER, 7/16
30 1 WASHER, Plain, 5/16
31 2 CAPSCREW, Hex Hd., 7/16-14 x 1-1/4
32 3 CAPSCREW, Hex Hd., 7/16-14 x 1
33 2 CARRIAGE BOLT, 1/4-20 x 7/8
34 3 WASHER, Plain
35 2 WASHER, Plain
36 1 NUT, Push On
37 1 CAPSCREW, Hex Hd., 7/16-14 x 3-1/2
44" Mower Deck - Deck & Arbors
Ref. Qt. Description Ref. Qt. Description
