8 - 11
8 Mower Deck Repair
44” Clutch & Support
1 1 SPRING
2 2 SPACER
3 1 V-BELT, Arbor Drive
4 2 GREASE FITTING
5 1 V-BELT, Mower Drive
6 1 SPRING
7 1 GRIP, Lever
8 2 SPACER
9 2 SPACER
10 4 BUSHING
11 1 IDLER, Stop
12 2 PULLEY, Idler (Includes Ref. No. 8)
13 1 LEVER ASSY, Idler
(Incl. Qty. 1, Ref. No. 3; Qty 2, Ref. No. 10)
14 1 LEVER ASSY., Idler Arm
(Incl. Qty. 1, Ref. No. 3; Qty 2, Ref. No. 10)
15 1 HITCH ASSY.
16 1 SPRING
17 1 ROD, Latch
18 2 NUT, Hex, 3/8-16
19 3 LOCKWASHER, 3/8
20 2 NUT, Hex, Lock, 3/8-16
21 2 CAPSCREW, Hex Hd., 3/8-16 x 1-1/2
22 1 CAPSCREW, Hex Hd., 3/8-16 x 3-1/2
23 2 WASHER
24 14 WASHER, 5/16
25 1 NUT, Hex, Flange, Two-Way Lock, 3/8-16
26 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
27 2 NUT, Push On
(used on early model Latch Rod, Ref. No. 17)
28 1 CARRIAGE BOLT, 3/8-16 x 2
Ref. Qt. Description Ref. Qt. Description
44" Mower Deck - Clutch & Support
