Simplicity LTH Series

8 - 13
8 Mower Deck Repair
44” Height Adjustment & Rollers
44" Mower Deck - Height Adjustment & Rollers
1 1 PIN, Clevis
2 2 RING, Retaining
3 1 BOLT, Shoulder, 3/8-16
4 1 CLIP, Pin, Safety
5 1 PIN, Roll, 1" Long
6 2 NUT, Hex, 3/8-16
7 2 LOCKWASHER
8 2 SPACER
9 6 SCREW, Hex, Taptite, 5/16 x 3/4
10 3 STRAP, Mower Arm Assy.
11 9 ROLLER
12 1 SLIDE
13 1 SHAFT ASSY., Roller, 44"
(Incl. Ref. Nos. 2, 8 & 46)
14 1 BAR, Roller
15 1 PLATE, Mower Support
16 1 TRUNNION
17 1 NUT, Adjuster
18 1 ARM, Rear, Mower, RH
19 1 TRUNNION
20 1 TRUNNION, Threaded
21 1 ROD, Adjustment
22 1 CRANK, Cutting Height
23 1 WASHER, Detent
24 1 UP-STOP, Mower
25 1 ARM ASSY., Mower
26 1 INDICATOR, Cutting Height
27 1 BRACKET, Cutting Height
28 1 LINK ASSY, Lift
29 1 SPACER
30 1 KNOB, Height Crank
31 2 NUT, Hex, Jam, 1/2-13
32 2 LOCKWASHER, 5/16
33 2 NUT, Hex, 5/16-18
34 1 COTTER PIN
35 1 COTTER PIN
36 1 WASHER, Flat, 5/16
37 2 CAPSCREW, Hex, 5/16-18 x 1-1/4
38 1 CAPSCREW, Hex, 3/8-16 x 1-3/4
39 1 WASHER, Plain, 1/2
40 12 WASHER, Plain, 1-1/4
41 5 WASHER, Plain
42 1 NUT, Hex, Whizlock, 3/8-16
43 2 NUT, Hex, Flange, Lock, 1/2-13
44 4 SCREW, Taptite, 5/16 x 1
45 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
46 2 WASHER, 5/8 x 1-1/4 x 1/16
47 1 PAL NUT
48 3 WASHER, 33/64
Ref. Qt. Description Ref. Qt. Description
