Simplicity LTH Series Service Manual

5 - 7
5 Electrical Troubleshooting
Main Wiring Harness
1 1 COVER, Terminal
2 1 CABLE, Battery to Solenoid
3 1 HOSE, Battery, Drain
4 1 WIRE ASSY.
5 1 CIRCUIT BREAKER
6 1 CABLE, Solenoid to Starter
7 1 HOLD DOWN, Battery
8 5 BULB, Indicator Light (Qty. 4 used on 15 HP models)
9 1 BOOT, Insulator
10 1 BATTERY
11 1 SOLENOID
12 1 IGNITION SWITCH ASSY. (Incl. Ref. Nos. 25, 26 & 35)
13 1 SWITCH, Transmission, Neutral Start
14 1 SWITCH, Headlight
15 1 MODULE
16 1 TRAY, Battery
17 2 NUT, Plastic, 1/4-20
18 1 SWITCH, Interlock, Clutch / Brake Pedal
19 1 STRAP, Wire Retainer
20 2 ROD, Battery Hold Down
21 1 WIRE ASSY.
22 1 CABLE, Battery to Ground
23 1 SWITCH, PTO Electric Clutch
24 1 HARNESS, Upper
25 2 KEY, Ignition
26 1 NUT
27 2 NUT, Hex, Full, 1/4-20 (15 HP models only)
28 2 LOCKWASHER, 1/4
29 2 LOCKWASHER, 5/16
30 2 NUT, Hex, 5/16-24
31 6 WASHER, Plain, 9/32
32 2 CAPSCREW, Hex, 1/4-20 x 3/4
33 7 SCREW, Plastite, #8-16 x 1/2
34 2 SCREW, Plastite, 1/4-20 x 1/2
35 1 LOCKWASHER, Internal Tooth, 5/8
REF.
NO. QTY. DESCRIPTION
MAIN WIRING HARNESS
