Chapter 1: Hardware overview 17
Callout Component Description
7 Serial port Serial RJ-45 connector.
8 1GbE network interfaces There are two embedded 1GbE
network interfaces numbered 1 and
2, from left to right. They are logically
named LAN1 and LAN2.
9 VGA video port (DB-15 connector) VGA port that provides KVM connector
for accessing the server console.
10 Server identification button Helps you locate an enclosure
within a rack. If you push the server
identification button on the back
panel (or the front panel), the server
identification buttons on the front panel
and the back panel flash blue. You can
push a button a second time to stop it
from flashing.
Environmental and technical specifications
There are specific environmental and technical specifications for each hardare platform. The
specifications help you when planning the appropriate installation location, environmental conditions,
and resources, such as power and cooling.
You can also review the product documentation at http://www.cisco.com/c/en/us/td/docs/
unified_computing/ucs/c/hw/C240M4/install/C240M4.html.
Enclosure size and weight
The following table describes the dimensions of the UCS C240 M4SX server, which is an industry-
standard 2U enclosure.
Table 5: Enclosure size
Specification Centimeters Inches
Height 8.7 3.43
Width (latch-to-latch) 44.8 17.65
Depth 73.8 29.0
Front clearance 7.6 3.0
The maximum weight all memory and drive configurations is approximately 62.7lb (28.4kg).
