Chapter 2: Install the server hardware 21
Part Description
Power cords (locale specific)
■ Two standard power cords.
■ Two rack power distribution unit (PDU) cords.
1 SFP+ Direct Attach (Twinax) cable Connects a 10GbE interface on one server directly to a
10GbE interface on another server. Depending on your
network configuration and the distance between the
server, you might need different or additional cables.
Sliding rail kit Contains the left and the right rails, two hook and loop
straps, and detailed installation documentation.
Cable Management Arm kit (optional) Contains the CMA assembly and installation
documentation.
Printed documentation
■ Hardware Installation Quick Start
■ Configuration and Deployment Quick Start
■ Product Information Guide (safety and regulatory
notices)
■ End User License Agreement
Hardware not supplied in the shipping carton
Your network environment might require additional hardware components not supplied in the shipping
carton.
Hardware Description Application
Rack 19 inch (48.3 cm), four-post,
toolless rack.
Provides easy access to
the server hardware in your
computing environment.
1GbE data cables Two Category 5E or Category 6
cables with RJ45 connectors.
An optional third cable is
required to use the IPMI port for
remote console access.
Connects the 1GbE network
interfaces on each server to a
1GbE switch. This is required
only if you are connecting the
1GbE network interfaces on
each server to a switch, such as
in a direct connected or switch-
connected network configuration,
for example.
