CR40
42
/50 MKII Radar operation Chapter 7
100
ready to load the radar display in the right half of the screen:
MENU
Call up the menu bar, and…
WIN
press the [WIN] key until the right half of the screen is highlighted in
the screen symbol in the top right corner of the menu bar
6,1
Select radar display from the radar menu
- you now have a chart and radar display presented on the same screen.
As an example you may want to try and match the ship’s position on
the two charts by setting them both to Head-Up orientation:
ENT
From chart display (left window), press [ENT], [9] Chart setup
Go to Orientation
+/-
Toggle to HEAD UP and RELATIVE modes
ENT
Confirm entry
WIN
Go to the radar display (right window)
