CR40/42/50 MKII Position menus Chapter 4
41
Set up speed diagram:
Scale for speed, max: +006kn
Scale for speed, min.: -001kn
Speed over ground (SOG): ON
Velocity made good (V): ON
Water speed (W): OFF
Time interval: 10 MIN.
The scale for
the speed
diagram can
be adjusted
in this
display.
Time inter-
val can be
set in 8
intervals
from 1
minute to 3
hours and
freeze.
Go to the function you wish to change
+/-
Key in new figure or change setting
ENT
Confirm entry and return to Speed diagram
4.4 Dual speed display
(trawling speed display)
The analogue differential speed indicator will show how much the
present speed varies from the average speed.
If the difference exceeds +/- 3 knots (or km/h or miles/h), an arrow
will appear which will be pointing out of the scale.
MENU
Call up the menu bar, and…
2,4
load dual speed display
- see next page.
