9.9.4 Connector’s pin numbers and wire colors
The connecting cable is supplied with the radar antenna. The 18-pin round
connector is connected to the main unit’s receptacle marked RADAR – refer to
section 9.7 for details on pin numbers.
The connector at the other end of the connecting cable is for the radar antenna,
and consist of the following pin numbers and wire colors:
Connector for the RB714A Radar antenna
Alternative colors:
Pin 5: Red
Pin 6: Green
Pin 7: Brown
Pin 8: White
Connector for the RB715A Radar antenna
Alternative colors:
Pin 4: Green
Pin 5: Red
Pin 6: White
Pin 7: Brown
101010 10
40mm
60mm
1
2
3
4
5
6
7
8
9
10
Violet
Blue
Orange thick
Yellow
Red center
Red shield
Brown center
Brown shield
Coax center
Coax shield
Shrinking flex
JST no. VHR-10N
Anritsu radar cable
main shield
101010 10
20mm
70mm
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
9
Violet
Blue
Not connected
Not connected
Yellow
Orange thick
Red thick
Red shield
Yellow thick
Red center
Green thick
Brown shield
Blue thick
Brown center
Coax shield
Coax center
Shrinking flex
JST no. VHR-9N
Anritsu radar cable
JST no. VHR-7N
