CR40/42/50 MKII NAV menus & navigation examples Chapter 6
71
6.2.5 NAV mode – Set & drift trim display
) The readings rely on data from external log and compass, and
navigation mode must be active.
The Set & drift trim display will provide information on actual and
mean speed, velocity and wind.
- see also section 4.2 Set & drift display.
MENU
Call up the menu bar, and…
4,4
load the Set & drift trim display
X: XTE
Cross-track-
error.
D: Distance
to point.
ENT
Open for change
ENT
Reset mean speed indication in display
6.2.6 NAV mode – Waypoint advance
½
MENU
Call up the menu bar, and…
4,5
activate shift to next waypoint
- it will require that navigation mode is active and that “anext
waypoint” exists.
Route: RTE 3 5
-3 -2 -1 1 2 3
-3 -2 -1 1 2 3
B: 258° X: 0.011nm D: 1.18nm
-3 -2 -1 1 2 3
W/kn
7.6
Av. W
7.2
Av. V
7.4
V/kn
7.2
Av. S
6.3
S/kn
7.4
0.02nm0.02nm
