CR40/42/50 MKII Installation manual Chapter 9
143
Interconnecting cable (RB716A)
1. Ensure that the radar is off.
2. Connect the cable to the receptacle marked RADAR on the rear panel of the
display unit.
3. Use a T-wrench to remove the back covers of the scanner unit.
4. Remove the two bolts securing the transceiver and pull out the transceiver
after removing two connectors (to Motor (X1), to Heading switch (X2) ).
5. Remove the four bolts securing the fixing plate at the cable entrance.
6. Remove the metal fixing plate, rubber seal and washer that secures the cable.
7. Pass the cable through as shown in the diagram below.
8. Replace the above items and tighten the bolts.
9. Return the transceiver to its original position and secure it with the removed
bolts.
10. Connect 7-pin connector to X11 and 9-pin connector to X12 of PCB.
11. Re-connect the two connectors removed at point 4.
12. Refit the scanner covers.
13. Take care the cable is not pinched when refitting the cover.
) See ‘Fitting interconnection cable’ on next page.
