CR40/42/50 MKII NAV menus & navigation examples Chapter 6
79
where you can choose which track you wish to select for navigation:
+/-
Scroll up/down in the track list until the correct track number / name
appears
Use the cursor to move around in the window if anything needs to be
changed – such as Direction in track, etc.
0-9
Key in the number of the first trackpoint you wish to sail to
- see display example on next page.
Navigate in track:
Track: TRACK 1 0001
Bearing: 224° Distance: 0.000nm
Direction in track: FORWARD
Navigation from your position: YES
XTE alarm: 00.10 OFF
Auto trackpoint shift: WP-line
Navigation mode: RHUMBLINE
ENT
Start navigation
A course line will now be drawn from ship’s position to the first point
of destination.
It is possible to mix and match the data you require to have on the
screen e.g. ½ window for the chart display, ¼ window for the
navigation display, and ¼ window for the Set & drift trim display or
ETA & AVN display, maybe. The choice is yours. Refer to section 2.1
Fundamentals of the PAGE and WINdow system.
GOTO
Pressing
[GOTO]
from chart display during navigation will activate an
INFO window with the following functions to choose from:
1. Advance (to next trackpoint)
2. Restart to approaching point (in case you have drifted off course)
3. Turn NAV OFF.
