Simrad CS66 Installation Guides

INSTALLATION
J3, J4
Not used.
COM 1, COM 2
NMEA channels used for connecting external equipment.
USB 2
USB.
TB 1
1
2
Pre-heat.
3
4
External ON/OFF switch.
5
6
Display illumination for the COP20 (OPTION).
Parallel
Printer port.
Power
24V DC or 115/230V AC power input.
20221867 / F 9
