Simrad CS66 4-channels Chart system
Note Data entered in the System Configuration dialog are not taken
into account until it is confirmed by clicking the OK or APPLY
buttons:
•OK: changes are applied, and the dialog box is removed from
the display
•APPLY: changes are applied, and the dialog box remains
displayed.
The different tabs in the System Configuration dialog are
described in the following pages.
Ref page:
Inputs:
Used to configure external devices. 15
Outputs:
Used for configuring the output format. 19
Checksum:
Used for checksum test for received data. 20
Aux settings:
Used for different hardware and software settings. 21
Misc:
Used for different operator parameters. 22
Ship:
Used for defining the ship size. 24
3.2 Input configuration
The Inputs tab in the System Configuration dialog is used for
configuring the input format for each interfacing serial channel.
The tab is also used to delete or edit an already defined input.
All defined input devices are listed alphabetically in the Input
tab. If no input device is configured, the dialog will be empty.
14 20221867 / E
