NSS overview | NSS Installation Manual
VIDEO IN
Optional
accessory
HD Radar
ECHOSOUNDER
BSM-1 or BSM-2
NEP-2
LSS-1
WEATHER
AUDIO
External GPS: GS15
Auto Pilot: AP28/AP24
Heading Sensor: RC42
Audio: SonicHub
Engines: NMEA2000
Digital Switching: CZone
Instruments: IS20
Graphic, Data, Wind
AIS: NAIS300 / AI50
Structure Scan
Echo Sounder
USA Only
iPod Dock
Sirius satelite weather
and radio
LSS-1 Transducer
Optional 2nd transducer
for high deadrise hulls
HD Radar
2,4,6,10 or 25 kW
Audio cable
NMEA2000 / SimNet
SimNet /
NMEA2000
POWER
NETWORK
NETWORK NETWORK NETWORK NETWORK
NSS12 NSS12
ETHERNET
SWITCH
TRANSDUCER
BROADBAND RADAR
BR24/3G
WM-2
Various inhull,
through hull, and
transom mount
options available
NSS12 potential system example
