Supported data | NSS Installation Manual

NMEA0183 supported sentences

TX / RX GPS

Receive GGA GLL GSA GSV VTG ZDA

Transmit GGA GLL GSA GSV VTG ZDA

Navigation

Receive RMC

Transmit AAM APB BOD BWC BWR RMC RMB XTE

Echo

Receive DBT DPT MTW VLW VHW

Transmit DBT DPT MTW VLW VHW

Compass

Receive HDG HDT HDM

Transmit HDG

Wind

Receive MWV MWD

Transmit MWV

AIS / DSC

Receive DSC DSE VDM AIS sentences are not bridged to or from

SimNet.

MARPA

Transmit TLL TTM These are only output sentences

Default Chapter5
