59
Accessory cables |
NSS Installation Manual
NMEA2000
SimNet / NMEA2000 Connector
3
4
5
1
2
Pin
F
unc
tion
1
CAN_H
2
SimNet power (+) 12
V DC
3
SimNet power (-)
4
Shield
5
CAN_L
Network (E
thernet)
NET
WORK (Ethernet) Connector
1
5
4
3
2
Pin
F
unc
tion
1
TX +
2
TX -
3
RX +
4
RX -
5
Gnd
Echosounder
Echosounder Connector
1
2
3
4
5
7
6
Pin
Function
1
Depth +
2
Speed
3 Speed
power
4
T
emp
5
Depth -
6
Shield
7
T
emp / speed Gnd
58
