CZone setup
In order to communicate with the CZone modules connected to the network, the NSS display
must be assigned a unique CZone Display Dipswitch setting.
The functionality of the CZone system is determined by the CZone Con g File (.zcf), which
is stored on all CZone modules, and supported Simrad displays such as the NSS. The le is
created using the CZone Con guration Tool, a specialised PC application available from BEP
Marine Ltd, and associated CZone distributors.
The NSS system provides a means to load the Con g le, as well as apply updates to module
rmware, removing the need to take a laptop computer aboard the vessel.
Enabling CZone functionality
Once CZone is enabled, an addtional CZone menu appears at the bottom of the Advanced
Settings page.
Assigning the dipswitch setting
Every Simrad product capable of controlling and viewing CZone devices must be assigned
a virtual dipswitch setting. This setting is unique for each device. Typically it is set after the
con g le already exists on the CZone system, but it may also be set in advance.
When the con g is already available on the network, it will immediately commence upload-
ing to the NSS once the dipswitch is set. Allow this to complete, without interruption.
Setting CZone to display at startup
With this option selected, the CZone control page will be shown rst, every time the NSS is
powered up.
CZone backlight control
Enabling this will cause the NSS to synchronize it’s backlight setting with that of any CZone
Display Interfaces set up to share backlight settings.
Import and backup a con g le
The les page may be used to import CZone con g les, or export a copy to a Micro SD card.
Importing will overwright the existing le on the NSS and all connected CZone devices.
For further information refer to ‘“Applying Software Updates” on page 53
Upgrading module rmware
The les page also allows the loading of CZone module rmware updates. For further infor-
mation refer to ‘“Applying Software Updates” on page 53
