Singer S-10 - Adjusting the Height of the Embroidery Foot

15
Adjusting the Height of the Embroidery Foot
Space between the needle plate and bottom of the embroidery foot should be 1.0 to 1.3 mm
when the presser bar is at the lowest position.
1. Remove the face cover.
2. Turn the handwheel to bring the presser bar to
the lowest position.
Lower the presser foot lifter.
3. Loosen the setscrew and move the presser bar
up or down to adjust the height of the embroidery
foot.
NOTE:
Make sure not to turn the presser bar.
4. Tighten the setscrew.
6. Attach the face cover.
Setscrew
Presser bar
Presser foot lifter
Embroidery foot
1.0 to 1.3 mm
Needle
