SKF Enlight Collect IMx-1 User Manual

PRODUCT SPECIFICATIONS
IMx-1 wireless sensor specifications
SKF Enlight Collect IMx-1 System
User Manual
Revision A
67 (84)
5 Product specifications
5.1 IMx-1 wireless sensor specifications
5.1.1 Environmental and physical
Table 4 Wireless sensor environmental specifications
Mounting
¼–28 UNF female, recommended torque 2.9 Nm (2.14 lb-ft)
Spanner/wrench
1–1/4 inch AF: Across Flats, 31.75 mm
Material
Thermoplastic housing
304L or 303 stainless steel base
Diameter (maximum at base)
33.66 mm (1.33 inch)
Height
78.2 mm (3.08 inch)
Weight
142 g (5 oz)
Operating
–40 to +85
0
C (–40 to +185
0
F)
Storage
Recommended maximum temperature: 30 °C (86 °F)
To avoid excessive self-discharge of the battery, do not store
at high temperatures (30
0
C or above) for extended periods.
The following design aspects and specifications are pending test and certification
Altitude
Maximum 5 000 m (16,404 ft.)
Humidity
Maximum 95% relative non-condensing
Conditions of use
Indoor or outdoor
Pollution degree
4
IP rating
IP69K according to ISO 20653:2013
Mechanical impact rating
According to IEC 60068-2-31, free fall procedure 1
Flammability
UL 94 V-0
Hazardous area rating
Currently safe area use only
(ATEX/IECEx Zone 1 pending)
