SKF Enlight Collect IMx-1 User Manual

PRODUCT SPECIFICATIONS
Enlight Collect gateway specifications
SKF Enlight Collect IMx-1 System
User Manual
Revision A
73 (84)
5.2.3 Internal measurement capabilities
Table 11 Gateway Internal measurement capabilities
Parameter
Specification
Status
Self-monitoring, network and sensor/mesh status monitoring
Supports @ptitude Observer event log
Temperature
Gateway internal
Range
Greater than gateway operating range
Other
Including: watchdog, supply voltage monitoring
Notes:
In addition to dynamic status information, static or rarely changing information such
as sensor hardware and firmware revisions and ID are also available. Errors and
change in status are generally available in the @ptitude Observer event log.
5.2.4 Interfaces
Table 12 Gateway interface specifications
Sensor
Sensor wireless mesh, 2.4 GHz ISM
OTA FW update
Yes, to all sensors associated with the gateway
App interface
WPAN IEEE 802.15.1
Network interface options
Ethernet or Wi-Fi
DHCP or fixed IP address
Ethernet (wired)
10/100/1000 Mbps auto negotiation and auto MDI-X
For the Ethernet 1 connector location refer Figure 2.
Wi-Fi
802.11a/b/g/n/ac
2.4 and 5 GHz
WPA2-PSK (WPA2-personal with AES encryption)
Time synchronisation
NTP for synchronisation of the internal real time clock
Two configurable NTP server IP addresses
Absolute accuracy of time stamped data: ±1 s
Manual synchronisation is possible in @ptitude Observer
Data buffering
More than 1-week of data. Storage: non-volatile, FIFO
Notes:
WPAN IEEE 802.15.1: Bluetooth SIG certification is pending.
Wi-Fi, WPAN and sensor wireless mesh radio can co-exist on 2.4 GHz ISM, band
OTA: Over-the-air device firmware updates
