Page 23
EN
Assembly instructions
Units
Mounting position: ....... Discretionary (where UC units are installed
lower than the maximum oil level, the cus-
tomer must seal flange/machine)
Ambient temperature: ..... -15 to +40 °C
.......................(-15 bis +55 °C
3
) )
(At higher ambient temperatures, note that
there is a reduction in performance of approx.
1% per Kelvin)
Pump
Nominal volumetric flow: . . See page 24
Type: .................. Gear pump
Design:
B 1.................... Standard gasket FPM
B 3018 ................ Pump with standard sealing for outlet under
lubricant level (only for UC)
Operating pressure:
Admission pressure ...... max. 2 bar
Outlet p
max
.............. See page 24
Lubricant ............... Mineral oils, synthetic and environmen-
tally friendly oils with an operating viscosity
between 20 and 1.000 mm
2
/s
Suction height ........... Max. 1200 mm (for max. tube Ø)
Technical data
Rated motor power
1
) 0.18
[KW]
0.37
[KW]
0.55
[KW]
0.75
[KW]
Rated voltage
at 400 V
0.65
[A]
1.22
[A]
1.73
[A]
2.1
[A]
Size 63C90 80C120
Type IM V18 or IMB14
Motor can be shifted by 90°
Type of voltage 3-phase AC voltage
Frequency
2
) 50 Hz
Voltage and rated power See table page 26
Protection class IP 55
Temperature class F
1) The motors are suited for a frequency of 50 or 60 Hz.
2) For connection with a frequency of 60 Hz, the speed and the volumetric flow
are increased by 20% (compared to the table specifications, basis 50 Hz).
3) On request -special marine application only
4.2.7 Series 2: Q
nominal
up to 10.8 l/min
