Assembly instructions
UC, Series 2 Technical data
Nominal volumetric flow
1
)
p=0 [l/min]
Operating pressure
p
max
[bar]
Flange Dim. A
1
)
[mm]
Dim. B
1
)
[mm]
Weight
[kg]
1.0
140
80C120 116.5 90.5
10.0
200
11.2
1.6
45
63C120 7.5
180
80C120 13.5
2.3
30
63C120
118.5 91.5
7.5
100
80C120
11.5
130
13.5
3.5
20
63C120
122 93
7.5
65
80C120
11.5
90
13.5
4.8
15
63C120
126 95.5
7.5
45
80C120
11.5
65
13.5
7
10
63C120
132.5 98.5
7.6
30
80C120
11.6
45
13.6
9
8
63C120
137.5 101
7.6
25
80C120
11.6
35
13.6
10.8
7
63C120
143 104
7.7
20
80C120
11.7
30
13.7
4.2.7 Series 2: Q
nominal
up to 10.8 l/min
1) see DWG page 22
