SKYJACK, Page 118
SJRT Compact Series
Engine Powered
Tilt Switch LED Operation
The following describes LED operation with the
system powered.
Green LED on The green LED on
continuously indicates normal
operation. Both tilt axes are
within the specified degrees
of the learned zero position.
The green LED flashing
indicates the aerial platform is
moving in or out of tilt angle
limits. The time delay has not
occurred yet.
Red LED on The red LED is on
continuously when the tilt
angle on one or more axes is
off more than the allowable
degrees from the zero
position.
Green and Red
LEDs on
Both LEDs on continuously
indicates a fault in the system
is detected. The switch does
not function.
After a period of 5 seconds
or on power up, the switch
attempts to return to normal
operation. If the fault is still
detected, both LEDs remain
on.
