Skyjack Compact Rough Terrain Series - Figure 6.4-9. Air Cleaner Assembly (Kubota Engine D902)

SKYJACK, Page 222
SJRT Compact Series
Engine Powered
Index
No.
Skyjack
Part No.
Qty. Description
- 137654 AR ENGINE KIT, Kubota D902, Air Cleaner Kit
1 104528 1 • CLAMP, Gear (#28)
2 137893 1 • HOSE, Inlet
3 133222 1 • CLAMP, Gear (#32)
4 136144 1 • ASSEMBLY, Air cleaner (Kubota)
5 137924 1 • • FILTER ELEMENT (Kubota)
6 136148 1 • BRACKET, Air cleaner band
136667 AR • • BOLT, Hex head (M8-1.25 x 30mm)
127940 AR • • WASHER, Flat (M8 - ZN)
121059 AR • • NUT, Hex (M8-1.25)
7 137895 AR • BOLT, Hex head (M8-1.25 x 35mm, Grade 8.8, ZP)
8 116218 AR • WASHER, Lock (M8)
9 137120 1 • BRACKET, Air cleaner
Figure 6.4-9. Air Cleaner Assembly (Kubota Engine D902)
M137891AA
1
2
3
4
8
7
9
6
5
