Skyjack Compact Rough Terrain Series - Figure 6.4-2. Air Cleaner Assembly - Kubota Dual Fuel Engine DF972

Index
No.
Skyjack
Part No.
Qty. Description
SKYJACK, Page 208
SJRT Compact Series
Engine Powered
- 136038 AR ENGINE KIT, Kubota DF972, Air Cleaner Kit
1 104528 1 • CLAMP, Gear (#28)
2 136145 1 • HOSE, Inlet
3 133222 1 • CLAMP, Gear (#32)
4 136144 1 • ASSEMBLY, Air cleaner (Kubota)
137924 1 • FILTER ELEMENT, (Kubota)
5 137924 1 • FILTER, Air
6 136148 1 • BRACKET, Air cleaner band
136667 AR • • BOLT, Hex head (M8-1.25 x 30mm)
127940 AR • • WASHER, Flat (M8 - ZN)
121059 AR • • NUT, Hex (M8-1.25)
7 136154 AR • BOLT, Hex head (M8-1.5 x 75mm, Grade 8.8, ZP)
8 116218 AR • WASHER, Lock (M8)
9 136153 1 • BRACKET, Air cleaner
10 136155 2 • SLEEVE, (8.38mm Inner DIA x 10.65mm Outer DIA x 40mm)
Figure 6.4-2. Air Cleaner Assembly - Kubota Dual Fuel Engine DF972
M137194AA
1
2
3
4
7
8
9
10
6
5
