Skyjack Compact Rough Terrain Series User Manual

SKYJACK, Page 148
SJRT Compact Series
Engine Powered
Figure 6.2-4. Scissor Arm Assembly Connecting Hardware
M135901AA_M135872AA_2
Outside End Pin Assembly
(With Cross Member Tube)
Inside End Pin Assembly
(Without Cross Member Tube)
1
2
13
12
11
10
9
8
7
6
5
4 3
2
3
2
3
Limit Switch Pin Assembly Center Pin Assembly
