Skyjack Compact Rough Terrain Series - Figure 6.5-16. Cabinet Locking Option

Index
No.
Skyjack
Part No.
Qty. Description
- 223151 1 CABINET LOCKING SERVICE KIT
1 223061 2 • BRACKET, Cabinet locking - Cabinet
2 223062 2 • BRACKET, Cabinet locking - Door
3 157759 8 • RIVET, Pop (0.1875” x 0.565”)
4 103991 8 • WASHER, Flat (#8)
5 223161 1 • INSTRUCTIONS, Cabinet locking brackets (Not Shown)
4
2
3
1
M63821AA
Figure 6.5-16. Cabinet Locking Option AC
