Skyjack Compact Rough Terrain Series User Manual

SKYJACK, Page 187
SJRT Compact Series
Engine Powered
Index
No.
Skyjack
Part No.
Qty. Description
Figure 6.3-15. Engine Cabinet Assembly
AD
- 135899 - ENGINE CABINET ASSEMBLY
1 147812 1 • WELDMENT, Engine cabinet
(Order Part # 136351 for Machines with Serial #’s 37002061 and Below)
2 147824 1 • WELDMENT, Mud guard
(Order Part # 137835 for Machines with Serial #’s 37002061 and Below)
3 115649 4 • NUT, Hex nylon lock (1/4”-20, Grade 5)
4 103995 19 • WASHER, Flat (1/4”)
5 103856 4 • BOLT, Hex head (1/4”-20 x 3/4”, Grade 5)
6 136395 2 • UHMW BLOCK, Engine cabinet
7 139688 4 • SCREW, Flat head machine (1/4”-20 x 1”)
8 138026 1 • STUD, Ball (13mm)
9 137246 1 • BRACKET, Battery
10 103980 8 • NUT, Hex head (1/4”-20, Grade 5)
11 103984 2 • NUT, Hex nylon lock (5/16”-18, Grade 5)
12 103996 4 • WASHER, Flat (5/16”)
13 102850 1 • HORN, 12 Volt
14 138025 2 • STUD, Ball (10mm)
15 137184 1 • GAS SPRING (2.5” stroke)
16 137135 1 • DOOR, Instrumentation panel
17 104000 4 • WASHER, Lock (1/4”)
18 137016 1 • HINGE, Instrumentation panel
19 103892 6 • BOLT, Hex head (1/4”-20 x 0.62”, Grade 5)
20 147590 1 • WELDMENT, Exhaust tube (
Machines with S/N 37002062 & Above)
21 110814 2 • CARRIAGE BOLT, (0.313-18 x 0.75, Grade 5)
(Machines with S/N 37002062 & Above)
22 103404 2 • WASHER, Lock (0.312) (
Machines with S/N 37002062 and Above)
23 100397 2 • NUT, Hex head (0.312-18, Grade 5) (Machines with S/N 37002062 & Above)
24 107952 1 WASHER, Bronze (1-1/4” Inner DIA x 2-3/8” Outer DIA x 1/8”)
25 119726 1 SWITCH, 12V Main disconnect
26 128620 1 ADAPTER, Negative battery post to 5/16” stud
27 128632 1 ADAPTER ASSEMBLY, 300A fuse positive battery post
128596 1 • CLAMP, Battery post single
128595 1 • FUSE, 300A
128597 1 • NUT, Battery post insulated
28 112125 2 PLYWOOD, (3/8*6*11)
29 103295 1 BATTERY, 12V (WET)
30 139263 1 ASSEMBLY, Tilt switch (ANSI/CSA, No outriggers)
117880 1 • SWITCH, Tilt 2.5 / 4.5 deg.
103855 2 • BOLT, Hex head (1/4-20 x 1/2, Grade 5)
104000 2 • WASHER, Lock (1/4”)
103980 2 • NUT, Hex head (1/4”-20, Grade 5)
31 (Ref.) - ASSEMBLY, Engine door
(For components, refer to Figure 6.3-20)
