Page #205 background image
SKYJACK, Page 205
SJRT Compact Series
Engine Powered
Index
No.
Skyjack
Part No.
Qty. Description
Part list continued from the previous page.
6 (Ref.) - ASSEMBLY, Air cleaner
(For components, refer to Figure 6.4-2)
7 (Ref.) - ASSEMBLY, Hydraulic Pump
(For components, refer to Figure 6.4-5)
8 (Ref.) - ASSEMBLY, Exhaust System
(For components refer to Figure 6.4-3)
9 136121 1 MODULE, Igniter control
10 (Ref.) - SOLUTION, Engine coolant (Antifreeze)
(Refer to Table 1.1.)
11 (Ref.) - OIL, Engine
(Refer to Table 1.1.)
12 137648 1 ASSEMBLY, Radiator plate
137481 1 • PLATE, Radiator SJ68XX
137643 1 • TRIM, Rubber long
137647 1 • TRIM, Rubber short
147142 1 • RESERVOIR, Coolant
(Order Part # 132519 for Machines with S/N 37001758 and Below)
- - • HARDWARE, Coolant reservoir (Machines with S/N 37001759 and Above)
103887 2 • • BOLT, Hex head (5/16-18 x 0.75, Grade 5)
103996 2 • • WASHER, Flat (5/16)
100397 2 • • NUT, Hex head (5/16-18 Grade 5)
103404 2 • • WASHER, Lock (5/16)
- - • HARDWARE, Coolant reservoir (Machines with S/N 37001758 and Below)
103962 2 • • SCREW, Rnd hd machined (10-32 x 0.500)
104185 2 • • WASHER, Lock (#10)
104003 2 • • NUT, Hex head (10-32)
103014 1 • GROMMET, Rubber (7/8)
133140 1 • BRACKET, Reservoir
13 113400 1 SWITCH, Temperature
14 102838 1 SWITCH, Oil pressure
15 103850 AR BOLT, Hex head (M10 x 1.25 x 30mm, Grade 8.8)
16 136665 AR BOLT, Hex head (M10 x 1.25 x 35mm, Grade 8.8)
17 103848 AR BOLT, Hex head (M10 x 1.25 x 20mm, Grade 8.8)
18 130884 AR WASHER, Lock (M10)
19 147634 4 MOUNT, Engine vibration control
20 137657 1 BRACKET, Exhaust
21 136033 2 BRACKET, Engine mount FR/RL
22 136032 2 BRACKET, Engine mount FL/RR
23 136264 1 MOUNT, Lower solenoid
24 113582 1 LIMITER, Solenoid
25 114709 AR NUT, FHN (1/4” - 28)
26 114684 2 PIN, Roll (1/8” DIA x 7/16”)
Part list continued on the following page.
Figure 6.4-1. Engine Assembly (Kubota Engine DF972) (Continued)
