SKYJACK, Page 219
SJRT Compact Series
Engine Powered
Index
No.
Skyjack
Part No.
Qty. Description
Figure 6.4-8. Engine Assembly (Kubota Engine D902)
1 137651 1 ENGINE, Kubota D902
137839 1 • CRANKCASE
137840 1 • PAN, Oil
137841 1 • CYLINDER HEAD
137842 1 • PUMP, Water
137843 1 • INLET-MANIFOLD
137845 1 • MANIFOLD, Exhaust
137846 1 • COVER, Cylinder head
137847 1 • FLYWHEEL
137848 1 • HOUSING, Flywheel
137849 1 • FILTER, Oil (Inner)
137850 1 • CARTRIDGE, Oil filter
137851 1 • DIPSTICK
137852 1 • PUMP ASSEMBLY, Injection
137853 1 • PUMP, Fuel transfer
137854 1 • NOZZLE HOLDER ASSEMBLY
137855 1 • PLATE, Speed control
137856 1 • STARTER
137857 1 • ALTERNATOR
137858 1 • BRACKET, Alternator
137859 1 • GUARD, Alternator
137860 1 • GLOW PLUG
137861 1 • THERMOSTAT
137862 1 • COVER, Thermostat
137863 1 • PULLEY, Fan
137864 1 • PULLEY, Fan Drive
137865 1 • BELT, Fan
137866 1 • MANUAL, Operators
137867 1 • WARRANTY STATEMENT
119185 1 • TIMER, Glow lamp
137873 1 • COUPLER, Alternator assembly
137649 1 • FAN, Pusher
2 133219 AR WASHER, Flat (M6)
3 121758 AR WASHER, Lock (6mm)
4 167051 AR BOLT, Hex Head (M6 x 1 x 30MM Gr. 8.8 ZN)
5 136441 1 BELL HOUSING, Kubota DF972
136440 1 • HUB, Coupling
136437 1 • HOUSING
136439 1 • FLANGE
136438 1 • KIT, Hardware
6 (Ref.) - ASSEMBLY, Air cleaner
(For components, refer to Figure 6.4-9)
7 (Ref.) - ASSEMBLY, Hydraulic Pump
(For components, refer to Figure 6.4-5)
Part list continued on the following page.
