SJRT Compact Series
Engine Powered
Index
No.
Skyjack
Part No.
Qty. Description
Figure 6.5-8. 800W Inverter Option
1 138093 1 CABLE, Welding #6GA, 1/4” x 8” x 3/8”, (103, 103)
2 138094 1 FUSE, 125 Amp
3 (Ref.) - LABEL, Fuse
(For components, refer to Figure 6.6-5)
4 103068 2 INSULATOR, Fuse
5 103855 AR BOLT, Hex head (1/4”-20 x 1/2”, Grade 5)
6 104000 AR WASHER, Lock (1/4”)
7 103995 AR WASHER, Flat (1/4”)
8 103892 AR BOLT, Hex head (1/4”-20 x 0.62”, Grade 5)
9 103856 4 BOLT, Hex head cap screw (1/4”-20 x 3/4”)
10 100400 4 WASHER, Lock (1/4”)
11 103995 4 WASHER, Flat (1/4”)
12 (Ref.) - WELDMENT, Base
(For components, refer to Figure 6.3-1)
13 137269 1 INVERTER, 12VDC, 110VAC @ 60HZ (ANSI/CSA)
137403 1 INVERTER, 12VDC, 110/220VAC @ 50HZ (CE)
AC
