SKYJACK, Page 241
SJRT Compact Series
Engine Powered
Index
No.
Skyjack
Part No.
Qty. Description
Figure 6.5-9. 110/220 Clamp Assembly Option
1 103078 AR CLAMP, Double G10
2 101632 AR BOLT, Hex head (3/8”-16 x 3/4” Grade 5)
3 103999 AR WASHER, Lock (3/8”)
4 103472 AR WASHER, Flat (3/8”)
5 103978 AR NUT, Hex head (3/8”-16 Grade 5)
6 125810 AR CLAMP, Double S470G5-1
7 103962 AR SCREW, Round head machine (#10 - 32 x 1/2”)
8 104694 AR WASHER, Flat (#10)
9 104185 AR WASHER, Lock (#10)
10 104003 AR NUT, Hex head (#10-32)
11 122501 AR SCREW, Machine hex washer head (3/8”-16 x 5/8”)
12 123764 1 CLAMP, Single G6
13 124763 1 LABEL, Ontario hydro
AB
